Selector Valve SV-04B

  • Selector Valve SV-04B
  • Selector Valve SV-04B
  • Selector Valve SV-04B
  • Selector Valve SV-04B
  • Selector Valve SV-04B
  • Selector Valve SV-04B

Model Numbers of Selector Valve SV-04B

  • Back and forth switching of two positions

  • RUNZE patented Sapphire valve rotor and stator, biocompatible, wear-resistance, anti-corrosion & high temperature, long service life

  • Small footprint suits limited spaces

  • Available with 6, 8, 10 ports and 1.2mm orifice High efficiency and maintenance-free stepper motor drive system via RS232/RS485/CAN

  • Low pressure injectors are available with fittings for tubing OD1.6/2.0/2.5/3.0/3.175/3.2mm

Selector Valve SV-04B



Specification of Selector Valve SV-04B

Configuration6 port8 port10 port
Orifice1.2mm
Dead VolumePort-to-Port 28.121μl
Dead Volume 5.207μl
Port-to-Port 28.67μl
Dead Volume 5.756μl
Port-to-Port 28.129μl
Dead Volume 5.215μl
Wetted materialPCTFE, Sapphire rotor/stator
Pressure rating0-0.5Mpa (air) / 0-0.6Mpa (water)
Origin detectionAuto reset to initial position when powered on (this function can be opened or closed)
Liquid temperature0-150℃
Connection1/4-28UNF
Replaceable partsStator replaceable, sealed rotor irreplaceable
TranspositionRandom start to any specific port
DriverNon-optional
Valve drive≤4s/circle
Baud rateRS232/RS485: 9600bps, 19200bps, 38400bps, 57600bps, 115200bps
CAN: 100Kbps, 200Kbps, 500Kbps, 1Mbps
Address & Parameter settingVia communication
Power supplyDC24V/1A
Max. power24W
Operating temperature0℃~+50℃
Operating humidity<80% relative humidity, non-condensing
Dimension (L*W*H)63.7*50.4*115.2mm
Net Weight0.437kg


Driver Port of Selector Valve SV-04B

Selector Valve SV-04B



Flow Configuration of Selector Valve SV-04B

Selector Valve SV-04B


Selector Valve SV-04B
