Multi Channel Syringe Pump

Multi-Channel Syringe Pump is a precision syringe pump specially designed for high precision liquid handling with a small footprint applied in limited spaces. The fluid path borosilicate glass, PCTFE, sapphire is workable for strong corrosive chemicals in a wide application range. It is available to select from a variety of syringe volumes and valve configurations.

  • Multi Channel Syringe Pump
  • Multi Channel Syringe Pump Manufacturer
  • Multi Channel Syringe Pump Wholesale
  • Buy Multi Channel Syringe Pump
  • Multi Channel Syringe Pump
  • Multi Channel Syringe Pump Manufacturer
  • Multi Channel Syringe Pump Wholesale
  • Buy Multi Channel Syringe Pump

Model Numbers of Multi Channel Syringe Pump

Multi Channel Syringe Pump Model Number


Product Structure of Multi Channel Syringe Pump

Multi Channel Syringe Pump Structure


Specification of Multi Channel Syringe Pump


Accuracy

≤1%@100% stroke

Precision (Repeatability)

0.3%-0. 5%@100% stroke

Rated stroke (control steps)

30mm (12000 steps standard, 24000 steps OEM)

Linear Speed

0.017mm/s - 5mm/s (media: water)

Running time (stroke)

6s - 1765s (media: water)

Resolution

0.0025mm (1 step)

Actuator

Ball screw (Lead 1mm)

Max. piston drive

≥80N

Sub. piston drive

≥40N

ILS syringe

25μL, 50μL,100μL,150μL, 250μL,500μL,1ml,1.25ml, 1.5ml, 2.5ml, 3ml, 5ml

Valve model

M01 M02 M03 M04 M05 M06 M10

Valve drive

≤280ms (switch between neighboring ports)

Wetted material

Borosilicate glass, PTFE, PCTFE, Sapphire

Max. pressure rating

0.7Mpa

Valve connection

1/4-28UNF

Syringe connection

1/4-28UNF

Communication

RS232/RS485/CAN

Baud rate

RS232/RS485: 9600bps, 19200bps, 38400bps, 57600bps, 115200bps

CAN: 100Kbps, 200Kbps, 500Kbps, 1Mbps

Address & Parameter setting

Communication

Power supply

DC24V/3.0A

Operating Temperature

5℃-55℃

Operating Humidity

<80% relative humidity, non-condensing

Dimension (L*W*H)

137*45*127mm

Net weight

1.44kg


Syringe Options of Multi Channel Syringe Pump


Multi Channel Syringe Pump

ILS Syringe

25μL

50μL

100μL

150μL

250μL

500μL

1ml

1.25ml

1.5ml

2.5ml

3ml

5ml


Valve Options of Multi Channel Syringe Pump


Multi Channel Syringe Pump Working Principle


Driver Port


Multi Channel Syringe Pump Driver Port



Dimension (unit: mm)

Multi Channel Syringe Pump Dimension
