OEM Syringe Pump

Name: OEM Syringe Pump
Brand: Nanjing Runze Fluid Control Equipment Co., LTD.

OEM syringe pump usually is customized with 50ml or 100ml in higher capacity liquid handling of OEM systems. High accuracy and high repeatability make this electric syringe pump very popular for constant specific volume dispensing system, the programmable control system also make it more flexible in different applications and fields.

Send Mail

Specification of OEM Syringe Pump

Volume	50ml, 100ml
Accuracy	≤1% @100% stroke
Repeat accuracy	0.3%– 0.7% @100% stroke
Pressure	0-1.0Mpa (air)	0-1.2Mpa (water)
Service life	3 million times no leakage (media: water)
Detection	Photosensor check original piston position for accurate location
Actuator	Ball screw (Lead 2mm)
Fluid path	Borosilicate cylinder, PTFE piston, PTFE outlet
Max pressure	Positive air pressure 0-1.0Mpa / Negative air pressure 0-0.05Mpa
Connection	1/4-28UNF
Communication	RS232/RS485/CAN
Baud rate	RS232/RS485: 9600dps, 19200dps, 38400dps, 57600dps, 115200dps CAN: 100Kbps, 200Kbps, 500Kbps, 1Mbps
Device add. & Parameter setting	Serial Pont
Dimension (LWH)	Different model different dimension
Power supply	DC24V/1.5A
Max Power	15W
Working temperature	5 – 55℃
Working humidity	< 80% relative humidity, non-condensing
Delivery time	About 20-25working days

Driver Port of OEM Syringe Pump

OEM Syringe Pump Driver Port

Port	Description	Port	Description
H	CANH	B+/B-	Phase B wiring
L	CANL	A+/A-	Phase A wiring
A	RS485 A	O1	Optocoupler wiring
B	RS485 B	O2
GND	GND	O3
RX	RS232 RX	V1
TX	RS232 TX	V2
-	DC24V positive	V3
+	DC24V negative	GND
